Transcend's PCIe M.2 SSD MTE310S has a compact form factor and high-quality 3D NAND flash, making it easy to upgrade a myriad of devices, from Ultrabooks and lightweight notebooks, to tablets and handheld gaming consoles. It is designed with multiple firmware optimization technologies, such as SLC caching and the LDPC ECC mechanism, both of which improve storage reliability and extend the drive lifespan. Ultimately, the MTE310S is a fantastic choice for enhancing overall performance and efficiency in the modern workplace.

Transcend's MTE310S features M.2 2230 form factor, ideal for Ultrabooks, lightweight notebooks, tablets, and handheld gaming consoles. Thinner and lighter when compared to a normal SSD, the MTE310S SSD gives your device a much-needed boost while also saving space.



Appearance
Dimensions Single-sided 30.0 mm x 22.0 mm x 2.23 mm (1.18" x 0.87" x 0.09")
Weight 4 g (0.14 oz)
Type
M.2 2230
Interface
Bus Interface
NVMe PCIe Gen4 x4
Storage
Flash Type
3D NAND flash
Capacity
512 GB
Operating Environment
Operating Temperature 0°C (32°F) ~ 70°C (158°F)
Operating Voltage
3.3V±5%
Performance
Sequential Read/Write (CrystalDiskMark)
Up to 5,000/3,500 MB/s
4K Random Read/Write (IOmeter)
Up to 330,000/690,000 IOPS
Terabytes Written (TBW)
600 TBW
Mean Time Between Failures (MTBF) 2,000,000 hour(s)
Drive Writes Per Day (DWPD) 0.33 (5 yrs)
Note
Speed may vary due to host hardware, software, usage, and storage capacity.
The workload used to rate DWPD may be different from your actual workload, which may vary due to host hardware, software, usage, and storage capacity.
Terabytes Written (TBW) expresses the endurance under the highest capacity.
Some motherboards only provide PCIe x2 connections for the M.2 slot, creating a bottleneck on even the fastest drives.
Warranty
Certificate
CE/UKCA/FCC/BSMI/KC/RCM
Warranty
Five-year Limited Warranty
