OVERVIEW

High speed. Big range. Serious durability.

Optimal for building-to-building deployments outdoors or floor-to-floor connectivity indoors, boost your RF signal in a specific direction for long range point-to-point connections with ProSAFE® 10 DBI Directional antenna at wireless 802.11n speeds.

NETGEAR Warranty
*This product is backed by a NETGEAR limited 1-year Hardware Warranty.
*http://www.netgear.com/about/warranty/
*ProSupport Lifetime 24x7 Advanced Technical Support. (Remote diagnostics performed by our technical experts for prompt resolution of technical issues).

TECH SPECS

Product Number
*ANT224D10
Wireless Signal
*IEEE 802.11g
Typical Application
*Indoor/outdoor
Maximum Outdoor Range*
*8.5 km (5.28 miles)
Frequency Range
*2400 - 2500 MHz
Gain**
*10 dBi
Beam Width
*Horizontal 33° Vertical 32°
Polarization
*Linear; Vertical
Operating Temperature
*from -30o to 80o C
Dimensions
*240 x 240 x 40 mm
Weight
*0.7 kg
Connectors
*Antenna - N Jack Male
*Lightening Arrestor - N Jack Male to N Jack Male
*Extended Cable - N Plug Female
Package Contents
*NETGEAR ProSafe Indoor/ Outdoor 10 dB 2x2 Directional Antenna ANT224D10
*2 lightning arrestors with 30 cm low-loss cables
*2 reverse N/SMA adapter
*Wall mount and pole mounting hardware
*Installation Guide and Warranty/ Support card
Ordering Information (all regions)
*ANT224D10-10000S

WEBSITE
*Technical specification: http://www.netgear.co.uk/business/products/wireless/accessories/ant224d10.aspx#tab-techspecs
