Description: Warranty: 12 months
Product code: INVSOL04
Size: 297,5 X 468 X 125 mm
Weight: 13.3kg
Output Voltage: 230V AC
Output frequency: 50Hz / 60Hz
Shape of the output voltage: Pure Sinusoid
Efficiency: 98%
Usable power (continuous): 3000W
Instantaneous power (impulsive): 6000W
Pobór mocy (bez obciążenia): 2W
Battery voltage: 48V
Maximum PV voltage (VOC): 145VDC
Inverter efficiency: 90% - 93%
AC voltage adjustment (battery mode): 220VAC - 240VAC (adjustable)
Charging voltage: 54.8V
PV voltage range for MPPT: 60-130VDC
Maximum PV power: 4000W
Maximum MPPT output current: 80A

Compatibility list:

Compatible with following battery models :

Compatible with following devices :
