960GB 2.5 inch SATA SSD, Consumer level, 3D NAND
Read speed up to 550 MB/s, Write speed up to 490 MB/s
Operating Temperature 0~70°C, Storage Temperature -40~85°C
TBW 310TB
5-year limited warranty

Basic Parameters
Application Scenarios As a new generation of 2.5" SSD product launched by Dahua, the C800 series adopt high-quality 3D wafer level chip and high-performance controller. It is consumer-grade solid state drive designed for personal desktops and notebooks. The product can process data efficiently and ensure quick start-ups. In multi-tasking, it can ensure high speed and stability.
Capacity 960 GB
Form Factor 2.5 inch
Port SATA III 6Gb/s
Net Weight Max 40 g (0.09 lb)
Gross Weight Max 70 g (0.15 lb)
Product Dimensions 100.20 mm × 69.90 mm × 7.00 mm (3.94" × 2.75" × 0.28")
Packaging Dimensions 140.50 mm × 105.50 mm × 15.50 mm (5.53" × 4.15" × 0.61")
Memory Component 3D NAND
Power Consumption 1910 mW(max) 790 mW (idle)
Bus Type SATA 3.0

Function
S.M.A.R.T Yes
TRIM Yes
Garbage Collection Yes

Performance
Sequential Read Up to 510 MB/s
Sequential Write Up to 460 MB/s

Environment
MTBF 1,500,000 hours
Operating Temperature 0°C to +70°C (+32°F to +158°F)
Storage Temperature –40°C to +85°C (–40°F to +185°F)
Operating Humidity 5%–95% (non-condensing)
Vibration Resistance 10-200Hz, 0.5G
Shock Resistance 1500G/0.5 ms (half sine wave)

Guarantee
TBW 310 TB
Warranty 5-year limited warranty
