Dahua monitor LM22-A200Y 21,45" VA/1920x1080/3000:1/10ms/250nits/VGA/HDMI/černý
Features:
· Light and cost-effective plastic housing;
· Ultra-narrow bezel , elegant appearance, plastic base;
· 178°H/178°V extra-wide viewing angle for overall viewing performance;
· High fidelity digital processing for a brilliant and vivid video;
· Support multiple signal inputs such as HDMI, VGA;
· Physical button control mode;
· Low energy consumption, long service life;
· Anti-blue light design,eye-protective.
Technical Specification
Display
Screen Size 21.45"
Panel type VA
Aspect Ratio 16:9
Resolution 1920×1080 (FHD)
Backlight LED
Brightness/Luminance 250 cd/?(max)
Contrast 3000:1
Display Color 16.7M(8bit)
Viewing Angle(H/V) 178°(H)/178°(V)
Response time(typ.) OD 6ms
Refresh Rate 100Hz (max
Signals
Input VGA×1, HDMI×1
Output NO
Speaker
Speaker NO
General
Power Supply DC 12V
Consumption (Standard) 22W
Consumption (Standby) ?0.5W
Net Weight 2.05kg (4.51lb)
Gross Weight 2.86kg (6.29lb)
Bezel Width 3.3mm(U/R/L) 15.2mm(B)
Wall Mount 75x75mm (3.0"x3.0")
Dimension with stand (W×H×D) 492.7x284.0x48.4mm (20“x11.6”x1.9”)
Package(W×H×D) 598x99x366mm (24.4“x4.0”x14.9)
Work Environment
Temperature 0C~40C (32°F~104°F)
Humidity 10%~85%
Accessory
Standard HDMI cable,Adapter,base
· Light and cost-effective plastic housing;
· Ultra-narrow bezel , elegant appearance, plastic base;
· 178°H/178°V extra-wide viewing angle for overall viewing performance;
· High fidelity digital processing for a brilliant and vivid video;
· Support multiple signal inputs such as HDMI, VGA;
· Physical button control mode;
· Low energy consumption, long service life;
· Anti-blue light design,eye-protective.
Technical Specification
Display
Screen Size 21.45"
Panel type VA
Aspect Ratio 16:9
Resolution 1920×1080 (FHD)
Backlight LED
Brightness/Luminance 250 cd/?(max)
Contrast 3000:1
Display Color 16.7M(8bit)
Viewing Angle(H/V) 178°(H)/178°(V)
Response time(typ.) OD 6ms
Refresh Rate 100Hz (max
Signals
Input VGA×1, HDMI×1
Output NO
Speaker
Speaker NO
General
Power Supply DC 12V
Consumption (Standard) 22W
Consumption (Standby) ?0.5W
Net Weight 2.05kg (4.51lb)
Gross Weight 2.86kg (6.29lb)
Bezel Width 3.3mm(U/R/L) 15.2mm(B)
Wall Mount 75x75mm (3.0"x3.0")
Dimension with stand (W×H×D) 492.7x284.0x48.4mm (20“x11.6”x1.9”)
Package(W×H×D) 598x99x366mm (24.4“x4.0”x14.9)
Work Environment
Temperature 0C~40C (32°F~104°F)
Humidity 10%~85%
Accessory
Standard HDMI cable,Adapter,base
ParametryPorovnání
Display port (monitory)
Ne
Dotykový displej (monitory)
Ne
Typ povrchu displeje (monitory)
Matný
Podpora VESA (monitory, TV)
Ano
Prohnutá obrazovka (monitory)
Ne
USB-C zpětné nabíjení ntb (monitory)
Ne
USB-C integrovaná dokovací stanice (monitory)
Ne
Pivot
Ne
Výškově nastavitelný
Ne
RJ45 (monitory)
Ne
Výrobce (monitory)
DAHUA
Technologie (monitory, TV)
LCD (LED podsvícení)
Úhlopříčka displeje (monitory, TV)
21,5"
Formát zobrazení (monitory)
16:9 (širokoúhlý)
Typ displeje (monitory)
LCD VA
VGA/D-SUB vstup (monitory)
Ano
DVI vstup (monitory)
Ne
USB (monitory)
Ne
Reproduktory (monitory)
Ne
Kontrast (monitory)
1 100:1 – 10 000:1
Doba odezvy (monitory)
10 ms
Jas (monitory)
250 cd/m2
Rozlišení (monitory, TV)
1920x1080 (Full HD)
Integrovaný TV tuner (monitory)
Ne
Barva (monitory)
Černá
HDMI počet (monitory, TV)
1
